|Traction Machine:||Gearless Traction Machine||Control System:||VVVF Integrated Control System|
|Door Opening:||Center / Side Opening||Elevator Buffer:||Oil Buffer|
|Door Machine:||VVVF Control Technology||Door Safety:||Infrared Light Beams|
630kg Luxury Passenger Elevator,
1.5m/s Luxury Passenger Elevator,
VVVF Control Electric Passenger Lift
630kg 1.5m/s Speed Passenger Elevator Modernization in line with the latest safety
Elevator modernization offers traction machine, control system and drive system solutions to improve your elevator's reliability, appearance, comfort and ride quality. The replacement of obsolete parts to the modern equivalent and bring your elevator in line with the latest safety and accessibility standards.
Due to technological backwardness of the old elevator control system,the elevator trouble will increase. Passenger elevator modernization can update your lift technology. Our passenger elevator adopts the globally recommended VVVF Integrated Control System. Integrated drive controller is the new generation of state-of-the-art elevator-specific control and drive device. With full consideration of the safety & reliability of elevator; inherent characteristic of elevator operation and specific feature of potential energy load for elevator, this series elevator integrated drive controller adopt advanced technology of frequency control of motor speed and intelligent elevator control as well as the integration of control & drive of elevator to make the further improvement of the product performance, easy-to-use property and cost efficiency.
No matter on design, manufacture, spare parts, technique or other sides, industrial standard is strictly followed, the same as other leading brands, even exceeding them on some details. All main parts are carefully selected from top-grade professional factories guaranteed by ISO9001 Quality Control System; the performance of complete machine is unquestionably perfect.
Elevator Traction Machines
Wellift passenger elevator adopts permanent magnet synchronous motor gearless drive with conversion efficiency reaching 100%, applies high permanent magnet materials, realizes miniaturization and high efficiency of the system free of gear oil and maintenance and electromagnetism interference, low noise.
Model No.: V8 PM Gearless traction machine
Traction ratio: 2:1
Loading Capacity: 400kg - 1600kg
Speed Range: 0.5m/s - 4.0m/s
Sheave groove No.: 4 / 5 / 6 / 7
Elevator Door System
Applied with VVVF control technology, running curve of door operator can be adjusted discretionarily, running safely and comfortably, low noise and credibility quality, easy to be adjusted and installed.
Opening Type: Center Opening and Side Opening
Opening width: 650mm, 700mm, 750mm, 800mm, 850mm, 900mm,
950mm, 1000mm, 1050mm, 1100mm, 1150mm,1200mm
Elevator Safety Components
Speed governor, safety gear, oil buffer, guide shoe and rope brake ,all safety components parts are carefully selected from top-grade professional factories, fully comply with GB7588-2003 standard ( equivalent to the EN81-1: 1998 standard), featuring professional product design, high quality, passing national type testing certification.
Standard Specification of V8 Passenger Elevator:
|Target market:||Commercial & Residential Building, Hospital, Hotel|
|Load(Kg)||400, 550, 750, 900, 1000, 1150, 1350, 1600|
|Speed(m/s)||1.0, 1.5, 1.75, 2.0, 2.5, 3.0, 3.5, 4.0|
Please feel free to contact us if you have any need for our products. Also you can visit our company website www.wellift.com to download product catalogues.
