Max Capacity 500KG Commercial Dumbwaiter , Modern Dumbwaiter Environment Friendly

Customer Reviews
Our elevator shaft was not sealed before, elevator cabin got smudge in one strong Typhoon. After wash and clean, the cabin steel looks like brand new again. Wellift do adopt good quality 304 stainless steel sheet for cabin & landing doors

—— Stacey Williams

Spare parts supply is speedy. Delivery is 3 days after order. The project daily operation is not affected.

—— Ajayi

Wellift specially design the elevator product to fit in my own house. So I don't need to revise the civil construction again. It saves me a lot of trouble.

—— Jason Tan

Our elevator has been under operation for more than 10 years, and they are still in good performance.

—— Roy Beltran

The customer service is good. Reply is very prompt, and technology support is professional.

—— Kevin

I'm Online Chat Now

Max Capacity 500KG Commercial Dumbwaiter , Modern Dumbwaiter Environment Friendly

Max Capacity 500KG Commercial Dumbwaiter , Modern Dumbwaiter Environment Friendly
Max Capacity 500KG Commercial Dumbwaiter , Modern Dumbwaiter Environment Friendly

Large Image :  Max Capacity 500KG Commercial Dumbwaiter , Modern Dumbwaiter Environment Friendly

Product Details:
Place of Origin: China
Brand Name: WELLIFT
Certification: Special Equipment Type-examination Certificate
Model Number: S500
Payment & Shipping Terms:
Minimum Order Quantity: One Unit
Price: USD3000 --- USD10000 per unit
Packaging Details: PLY-board, Paper Box & Nude packed etc.
Delivery Time: 30 work days
Payment Terms: T/T, L/C
Supply Ability: 1000 Unit per month

Max Capacity 500KG Commercial Dumbwaiter , Modern Dumbwaiter Environment Friendly

Type: Window Type & Floor Type Max Capacity: 500kg
Rated Speed: 0.4 M/s To 1.0 M/s Name: Commercial Dumbwaiter
Optional Control: Frequency Control Opening Method: Manually Or Automatic
Shaft: Without Shaft (100kg To 300kg) Cabin Material: Painted Steel Or Stainless Steel
H.S. Code: 8428109000 Warranty: 18 Months
High Light:

kitchen food elevator


commercial dumbwaiter


Max 500Kg Service lift dumbwaiter elevator with PLC Control environment-friendly


Our Service lift dumbwaiter adopts PLC computer control with low malfunction rate, convenient maintenance and low cost. For safety, the Service lift stops in case the power for contact coil is lost and the contact can’t be disconnected. The diagnosis fault is displayed via corresponding code.

Our service lift has the advantages of small volume, complete functions, smooth delivery, low price and other characteristics, widely used in transporting food restaurants and factory canteens, libraries and other debris transported, our Service Lift product are exported to Philippines, Bangladesh, Uzbekistan, Saudi Arabia, Albania, Russia, Nigeria, South Africa, India, and other countries, we gain high recognition and praise by user.


Standard Specification of Dumbwaiter elevator / Service Lift

Load(Kg)   100, 200, 300, 400, 500
Speed(m/s)   0.4, 0.75, 1.0
Most Stops   12
Max. Journey   50m


Dumbwaiter elevator / Service Lift Standard Configurations


The control system adopts PLC control, serial communication and frequency control (Optional)


Equipped with service lift-use traction machine


Special door slide technology introduced from Italy


New generation of electromechanical integrated hall door lock-master/slave double lock (imported) together with electric locking system is more safe and reliable


All door system components, such as landing door, jamb and landing door device, are assembled tested in factory before delivered as a complete system, as well as the car door(optional)and door system


Equipped with service lift-use water-and oil-proofing buttons and digital calling board


Elevator steel frame is made of high corrosion-resistant hot-dip galvanized sheet of one-step forming structure which increases the structural strength of the elevator in addition to anti-corrosion, and is easier and more convenient for installation


Equipped with service lift-use rail -cold-drawn T-type solid rail


Door opening method: electric unlocking and manual up/down bi-parting door.



Perfectness Improvement


New generation of door-motor system together with wholly delivered landing door system after factory assembling and testing ensures high installation quality and less failures.


Water- and oil-proof buttons and digital calling board is more suitable for special working environment of service lift and dumbwaiter lift.



Control system function for Dumbwaiter elevator / Service Lift

Calling landing section

Water- proof and oil-proof calling board and digital display panel

Specially designed for working environment of service lift and dumbwaiter lift.

Sweet arrival prompt--Friendly arrival bell

Electrically locking function

The station calling board is equipped with electric lock for opening /closing the control circuit of lift

Calling response function

After pressing the calling button, the digital button LED for the called floor will light up.

And the memory will be canceled and the LED will be off after arrival

Control section

Fault display function

Display the diagnosed fault via corresponding code.

Contactor adhesion protection function

If the contactor coil fails to break after power loss, then prevent it from rerunning for safety purpose

Door opening/closing indication function

The landing door opens after the lift reaches the floor, and the status is displayed in digital to prompt the lift is operating in the current floor.

Running fault protection function

The lift stops after exceeding normal running time for 10 seconds to avoid burning of motor.

Running direction display function

The running direction is displayed via Up/Down flashing arrow.

Door-motor section

Equipped master/slave double lock function for landing door device as well as locking detection function

Electric locking door-motor system function

Avoid contact of door vane during operating, thus to improve the safety and reliability of lift

Electric unlocking of hall door via door-motor system

Push the opening button for each floor to unlock electrically after the lift reaches the floor

Lift structure

The service lift with capacity of 100kg-300kg is with frame structure. Machine room or well is not required


Our Dumbwaiter elevator and Service Lift are of high configurations and complete functions, and are built with dependable quality to last a lifetime. We invite you to compare this type elevator to any competitor, and you will find it superior in design and quality.


Please feel free to contact us if you have any need for our products. Also you can visit our company website www.wellift.com to download product catalogues.
