Product Details:
|
Name: | Lift Speed Governor | Rated Speed:ght P+Q:: | 0.25~2.5m/s |
---|---|---|---|
Rope Wheel Diameter:: | Ф240mm | Wire Rope Diameter: | Ф8mm |
Model: | XSQ115-09 | Hoisting Herght:: | ≤110m |
Usage: | Hoistway Safety Parts | Warranty: | 12 Months |
High Light: | elevator replacement parts,precision elevator parts |
Bidirection Overspeed Elevator Spare Parts / Lift Speed Governor Wire Rope Diameter Ф8MM
Bidirection overspeed governor
This overspeed govermor is one way, and for machine room elevator
Using with bidirectional safety gear and mechanical rope brake together
Rated speed: | 0.25-2.5m/s |
Sheave pitch: | Ф240mm |
Wire rope diameter | Ф8mm |
Rope pulling force: | 1000-2000N |
Overspeed switch voltage grade: | DC110V or AC220V |
G table : G01 | Match with bidirectional safety gear |
G table : G02 | Match with rope brake |
Please feel free to contact us if you have any need for our products. Also you can visit our company website www.wellift.com to download product catalogues.
