2 Horizontal Steps Shopping Mall Escalator With Automatic Lubricator Maintenance

2 Horizontal Steps Shopping Mall Escalator With Automatic Lubricator Maintenance
2 Horizontal Steps Shopping Mall Escalator With Automatic Lubricator Maintenance

Large Image :  2 Horizontal Steps Shopping Mall Escalator With Automatic Lubricator Maintenance

Product Details:
Place of Origin: China
Brand Name: WELLIFT
Certification: Special Equipment Type-examination Certificate
Model Number: W8
Payment & Shipping Terms:
Minimum Order Quantity: One Unit
Price: Negotiable
Packaging Details: Export package
Delivery Time: 40 working days
Payment Terms: T/T, L/C
Supply Ability: 1000 Unit per month

2 Horizontal Steps Shopping Mall Escalator With Automatic Lubricator Maintenance

Product Name: Shopping Mall Escalator Inclination: 30°, 35°
Step Width: 600, 800, 1000mm Travel Height: 2800-8400mm
Speed: 0.5m/s Type: Indoor Or Outdoor With Shelter Above
Horizontal Steps: 2 Steps HS Code: 8428400000
Power Supply: 380V 3PH 50HZ Dispose Type: Parallel Or Cross Arrangement
High Light:

indoor escalator


heavy duty escalator


VF Drive Indoor Escalator adopts Automatic Lubricator Maintenance Friendly


WELLIFT W8 serial escalator adopts automatic lubricator, it is controlled by micro-computer. It can automatically lubricate all essential elements periodically, escalator control system gives lubricating signal within the set period, and lubricating time can be set depending on actual working conditions. Escalator lubricator automatically connects with hydraulic pump for oiling and lubrication. This device can greatly lighten the work load of routine maintenance, as well as prolong the service life of transmission gear.


WELLIFT W8 serial escalator has unbeatable advantages on safety, operation appearance and energy saving in this trade. It is applicable for hotels, office buildings, shopping center, etc with good quality and competitive price.


Standard Specification of W8 serial escalator

 Target market:   Shopping mall, Commercial Building, Hospital, Hotel etc.
 Step width   600mm, 800mm, 1000mm
 Speed(m/s)   0.5
 Inclination   30°, 35°
 Max. Vertical rise   ≤8000mm
 Operating environment   Indoor or outdoor with Shelter


Superior Performance of W8 serial escalator


“Safety the first" is the basic guideline of W8. The design, manufacture and installation all reach or exceed GB16899-2011 and EN115 "Safety rules for the construction and installation of escalators and passenger conveyors”. Standard models possess safety equipments as following:

  • Emergency stop button
  • Skirt-plate safety device
  • Comb plate safety device
  • Anti-reverse safety device
  • Motor overload protection
  • Handrail entry safety device
  • Phase monitoring protection
  • Over speed protection
  • Yellow painted demarcation line
  • Step level check protection device
  • Lighting for the gape between steps
  • Circuit ground contact fault protection
  • Broken handrail monitoring safety device
  • Safety protecting device for step chain scission
  • Safety protecting device for drive chain scission
1 W8 runs smoothly, comfortable and safe to take. It is the perfect combination of ideal design solution and up-to-date technical achievement
2 The truss are made of special bar sections and rectangle steel tube, with stress relieving treatment, so that to be solid, durable and nondeformable
3 The drive device adopts the most advanced technology of German FRANDER Company which has the features of high efficiency, uniform operation and low noise
4 The control system adopts Japanese new-generation PLC technology, which can perform function setting and trouble self-diagnose, the remote monitoring interface can be added if necessary
5 The steps which formed from High-strength whole piece die-cast aluminum or stainless steel, and high-quality handrail guarantee the handsome appearance, safety and durability of escalator.
6 Following ISO9001 Quality Control System, each W8 escalator is manufactured and tested carefully to be of good quality
  New Standard Configurations

Automatic oil lubricator:

It can automatically lubricate all essential elements periodically; lubricating time can be set depending on real working conditions. This device can greatly lighten the work load of routine maintenance, as well as prolong the service life of transmission gear.

Automatic trouble display:

The trouble display screen in control cabinet of escalator will indicate the abort situation with 2-digit codes, so as to shorten needed time for diagnosing and repairing.

Remote monitoring interface

After adding this interface in computer, the managing center can use remote measuring device to monitor every escalator in building.

All operating parameters would be monitored and recorded for efficient control; or with remote system in WELLIFT maintenance department, we can monitor all conveying system and provide prompt service to customer.

  Optional Function

Photoelectric Induction System

W8 equips photoelectric induction system on upper and bottom inlets/outlets, which can realize the functions of self start and self stop.

VF drive system:

Equipped with advanced frequency transformer and encoder, combined with photoelectric inductor, W8 can automatically control speed according traffic flow with 60% energy saving and 80% less of peak current.

  Elegant Design
  • With up-to-date technology and daring imagination, we keep improving mechanical performance and visual effect of escalator, creating a perfect combination of high technology and artistic quality.
  • W8 not only possess thoughtful safety protection device and excellent carrying capacity, but also decorated with graceful balustrade, slender handrail and brisk step, which create a beautiful scene in busy city and give you pleasant feeling while taking escalator.
  Decorative Selection
  • With elegant appearance, advanced technology and smart design, W8 is harmonious with various circumstances. You can select suitable handrail glass and tread according to building style
  • Standard color of handrail is black, other 4 colors (blue, green, grey, red) are available with additional charge.


WELLIFT V8 serial escalators fully apply the novel materials and the advanced domestic and overseas technology for design and manufacture. The escalators have the consummate structure, elaborate stairway, delicate belt, attractive outline, they are widely applicable for large passenger flow areas such as the shopping centers, supermarkets, subways, and airports etc. it adds a charming mobile view for vast constructions.


Please feel free to contact us if you have any need for our products. Also you can visit our company website www.wellift.com to download product catalogues.
