2000KG Industrial Goods Passenger Lifts , Standard Shaft Warehouse Freight Elevator

2000KG Industrial Goods Passenger Lifts , Standard Shaft Warehouse Freight Elevator
2000KG Industrial Goods Passenger Lifts , Standard Shaft Warehouse Freight Elevator

Large Image :  2000KG Industrial Goods Passenger Lifts , Standard Shaft Warehouse Freight Elevator

Product Details:
Place of Origin: China
Brand Name: WELLIFT
Certification: Special Equipment Type-examination Certificate
Model Number: T5
Payment & Shipping Terms:
Minimum Order Quantity: One Unit
Price: Negotiation
Packaging Details: Export package
Delivery Time: 60 work days
Payment Terms: T/T, L/C
Supply Ability: 1000 Unit per month

2000KG Industrial Goods Passenger Lifts , Standard Shaft Warehouse Freight Elevator

Name: Industrial Freight Elevator Door Safety: Infrared Light Beams
Door Drive: Automatic With VVVF Control Door Knife: Single Or Double
Control System: VVVF Control System Shaft: Concrete Or Steel Structure
Voltage: 380V Or Local Voltage Max. Speed: 1.0m/s
Loading Capacity: 2000kg H.S. Code: 8428101090
High Light:

industrial freight elevator


heavy duty elevator


Industrial freight elevator 2000kg Standard Shaft for Warehouse Goods lift


With solid car structure, handpicked plate materials, super fixed parts of leading rail, efficient motor driving device, Wellift freight elevator enjoys powerful carrying capacity and sense of security and can stand up high frequent use and long duration of the time.

Wellift freight elevator makes a perfect combination of the latest controlling and driving techniques with solid car and mechanic structure and makes a comprehensive upgrade in terms of system configuration and functional options. Even in case of the most complicated freight transportation environment and the most exceptive functional requirements, our Cargo Elevator / Goods Elevator / Freight Elevator can handle without difficulty.


Standard Specification of 2000kg Goods Elevator / Freight Elevator

Model   T5
Rated capacity(kg)   2000
Rated speed (m/s)   0.5, 1.0
Type of car door

  Auto Side opening door with VVVF drive

  (Two panel sliding)

Car outside Dimension (W X D X H )   2000mm width x 2400mm depth x 2200 mm High
Landing Doors Entrance (W X H)   1600mm width x 2100 mm High

Shaft Size(Width X Depth)

  2900mm Width x 2700 mm Depth
Overhead(mm)   ≥4500
Pit Depth(mm)   ≥1500
Machine room Position   Above shaft

Machine room Size (W X D X H )

  2900 mm width * 3500 mm depth * 2500 mm High


Cargo Elevator / Goods Elevator / Freight Elevator Main Configurations:

Control system:

  Modularized micro-computer full collective selective control,

  long-distance monitor available

Driving system:

  AC-WVF(Variable voltage-variable frequency)drive system

Door system:

2-panel auto telescopic side opening door or auto center opening

door with WVF drive

Safety device:

  Door safety protection of infrared light beams

Car plate:

  2mm thick plastic spray steel plate with reinforcing steel bars

Car floor:

  Hardwood floor and 6mm thick anti-slip steel plate with pattern


Function for Cargo Elevator / Goods Elevator / Freight Elevator

 S Standard Function                                            O Optional Function

  Information Functions

  Landing alarm


  Digital indicator of floors


  Voice landing announce


  Functions for Disabled (Braille Button, Voice Announcer)


  Traveling Function

  Up-down full selective collective


  Direct landing


  Repeating open


  Overload display buzzer


  Car automatic homing to GF


  Reverse instruction cancel at terminal landing


  Quiet blower cross flow fan in car


  2 sets parallel operation


  Emergency Communication Function



  Conference mode


  Special Service Functions

  Auto/attendant service


  Independent service


  Auto lock at home landing


  Freewill service landing setting


  Tele-monitor interface reservation


  Emergency Function

  Emergency car lighting


  Fire protection operation


  ARD--- Automatic Rescue Device


  Safety Functions

  Door infrared light-beams safety protection


  Over-load display buzzer


  Safety circuit protection


  Over speed protection system


  Off-side protection at terminal landing


  Transducer breakdown protection


  Main-control CPU protection


  IC card access control


  Maintenance Functions

  Inspection operation


  Trouble self-diagnose record


  Long-distance maintenance monitor



Our T5 freight elevator is of high configurations and complete functions, and is built with dependable quality to last a lifetime. We invite you to compare this goods elevator to any competitor, and you will find it superior in design and quality.


Please feel free to contact us if you have any need for our products. Also you can visit our company website www.wellift.com to download product catalogues.
